Home > Basic TV 32”

Basic TV 32”

Your Go-To Basic TV​

Affordable
High-Quality
Versatile​

Narrow Frame Design

Caixun Basic TV adopts narrow frame design technology.

Rich Interface, More Application

Equipped with a variety of interface types, you can connect multiple devices at the same time to perform more functions.

COAXIAL *1

Connect the SPDIF receiver

HDMI *3

Digital signal input from HDMI video

ANT 75 *1

Connect the antennal / caddle TV input

USB Input *2

Connect a USB device here to play its media files or to record programs via the PVR function

YPbPr Input

Connect to your composite terminal of your DVD / VCR

AV Input *1

External AV signal input and relevant right / left sound channel

Terms & Conditions

*The products shown on this page are for reference only and may not reflect the actual product. The colour and finish of the actual product may vary slightly in different environments.
*The images of features shown on this page are for reference only and may not reflect the actual product or its configuration.
*The products shown on this page are for reference only and may not reflect the actual product. The colour and finish of the actual product may vary slightly in different environments.
*The images of features shown on this page are for reference only and may not reflect the actual product or its configuration.


Where to Purchase

Find your nearest Caixun’s Dealer!
It's now easy to own a Caixun!

LOCATE US →

Basic TV 32”



Basic TV 32”

Dimension (mm)

Inches 32"
Product Dimension W * H * D 720.2 x 422.8 x 77.6
Carton Dimension W * H * D 778 x 490 x 110

Weight (kgs)

Gross Weight 5.2
Net Weight 3.9

Hardware & Software Infomation

Operating System Basic TV
WIFI N/A
Bluetooth N/A
RAM N/A
Internal Storage N/A
CPU N/A
GPU N/A

Display

Aspect Ratio 16:9
Resolution 1366 x 768
Display Colors 16.7m

Antenna and Broadcasting

Analog TV NTSC (PAL/SECAM)
Digital TV ATSC (DVB-T2)

Audio

Dolby Digital Plus N/A
MultiStream Decoder N/A
Stereo Sound YES
Equalizer YES

Built in and Supporting Apps

Chromecast N/A
Hey Google N/A

Ports

RJ45 1
OPTICAL 1
EARPHONE 1
HDMI 3
AV IN 1
TV(DVB-S/S2) 1
TV(DVB-C/T/T2) 1
USB 2
CI 1
VGA(D-Sub 15pin) N/A
SCART N/A
Display Port N/A
COAXIAL 1

Rating and Voltage

Power consumption(Operation) 56W
Power consumption(Standby) ≦0.5W
Power Requirement AC 100-240 50/60Hz

Package Contents

User Manual 1 Pcs
Base Stand 1 Pair
Remote Control 1 Pcs
Battery 1 Pair
